VANTIVA CGA2121

VANTIVA CGA2121

The CGA2121 is a DOCSIS / EuroDOCSIS 3.0 cable gateway and offers next to 8 bonded upstream channels, 24 bonded downstream channels for wired gigabit download speeds of up to 1.2 Gbps.

Next-Gen Wi-Fi Technology for Next-Gen Speeds

Featuring the next-generation IEEE 802.11ac Wave 2 Wi-Fi standard for the 5 GHz band, this dual band Wi-Fi solution makes optimal use of the radio spectrum. With its optimized antenna configuration, the CGA2121 enables even higher throughput and better coverage over the much less crowded 5 GHz radio. At the same time, it guarantees uninterrupted transmission of data services over IEEE 802.11n using the 2.4 GHz band.

Features:

• 24×8 Channel Bonding
• EuroDOCSIS 3.0 compliant
• Dual mode DOCSIS / EuroDOCSIS
• Backward compatible with (Euro)DOCSIS 2.0 (and older)
• Full Band Capture Tuner
• Built-in RF Spectrum Analyzer
• 4 GE LAN Ports
• WiFi Networking on-Board: IEEE 802.11n 2.4 GHz (2×2), IEEE 802.11ac 5 GHz (3×3)
• WiFi Hotspot Functionality
• 2 FXS Ports for Phone or Fax
• PacketCable / EuroPacketCable 1.5 and 2.0 compliant
• 1 USB 2.0 Master Port
• Seamless Media Sharing (UPnP AV)
• MPEG2 over IP Encapsulation Solution
• Advanced Security Features
• TR-069 Remote Management
• IPv4 and IPv6 DS-Lite Support
• Designed to meet the latest ECO Standards

Power Supply:

• 12 V DC
• 2.5 A
• 30 W
