CMTS Docsis 16x 4 channel 3.0, 2.0
Professional CMTS for stable and fast cable networks.
Offers 16 downstream and 4 upstream channels for high capacity and reliable performance.
Perfect for ISPs and large network operators requiring scalability and continuity.
| Item — CMTS Docsis 16×4 (3.0, 2.0) | |
|---|---|
| Chassis | 1U 19″ Rackmount |
| DOCSIS | 3.0 (backward compatible with 2.0) |
| Downstream Channels | 16× SC-QAM |
| Upstream Channels | 4× ATDMA |
| Uplink Ports | 2× GE uplink (RJ45 / SFP) |
| Management Ports | RJ45 Console, RJ45 Control |
| Management | Web GUI, CLI (Console/SSH), SNMP v2/v3 |
| Monitoring | Real-time modem status, RF levels, logs, flap-list |
| Provisioning | DHCP/TFTP/ToD – multiple service tiers & QoS |
| Security | BPI+, ACLs, Traffic Filtering |
| IPv6 Support | Dual-stack IPv4 / IPv6 |
| RF Section | Downstream: up to 16× SC-QAM Upstream: up to 4× ATDMA RF connectors: F-type |
| Status Indicators | LEDs for Power, Alarm, Cable Activity |
| Power Supply | AC 100–240 V |
| Cooling | Active cooling with fans |
| Dimensions/Weight | t.b.c. |
| Ordering Info | ||
|---|---|---|
| Product Model | Product Specification | Accessories |
| CMTS Docsis 16×4 | 16× Downstream, 4× Upstream, 2× GE uplink, AC power | Rackmount kit, Console cable, Power cord |
Future-Ready CMTS for Growing Networks
DOCSIS 3.0 / 2.0 with stable 1 Gbps throughput
Future-Ready CMTS for Growing Networks
DOCSIS 3.0 / 2.0 with stable 1 Gbps throughput
Reliable CMTS for Mid-Scale Networks
DOCSIS 3.0 / 2.0 • 16×4 Channel Bonding • Up to 1 Gbps Throughput
Reliable CMTS for Mid-Scale Networks
DOCSIS 3.0 / 2.0 • 16×4 Channel Bonding • Up to 1 Gbps Throughput
| Weight | 4,5 kg |
|---|---|
| Dimensions | 48,3 × 30 × 4,4 cm |
| Rackmount | 1U 19-inch |
| Power Supply | 100–240V AC, 50/60 Hz |
| Upstream Channels | 4 |
| Downstream Channels | 16 |
